詳細情報 |
|||
| 材料: | 銅とアルミニウム | 製品寸法: | カスタマイズ可能 |
|---|---|---|---|
| 製品重量: | 3.4kg | 特徴: | 新技術と高出力冷却 |
| 表面処理: | 油の洗浄と酸化防止 | 熱伝導力: | 450 W |
| 製品技術: | 溶接・パイプ曲げ加工 | タイプ: | アルミニウムプロファイル |
| 熱伝導率: | ≧180W/m・K | 素材の質感: | 6061 |
| チューブ寸法: | K-1/4”、K-3/8”、K-1/2” | 耐食性: | メッキまたは陽極酸化により高い |
| 厚さ: | 0.30mm--カスタマイズされた | 取り付けオプション: | ネジ穴または粘着パッド |
| 湿度: | 5%～90% | 重さ: | サイズや材料によって異なります |
| 処理: | 不動態化熱伝導 | 応用: | RGBレーザー光源 |
| 製品重量: | 1.198kg | 本体材質: | アルミニウム |
| 電源インターフェース: | 3ピン | 寸法: | カスタマイズ可能 (例: 100mm x 100mm x 10mm) |
| 熱伝導力: | 275W | 製品名: | 液体冷却プレート |
| 追加処理: | CNC加工 | 材料: | 銅+アルミニウム合金 |
| 納期: | 少なくとも1バー | 冷却方法: | 内部チャネルによる液体冷却 |
| 表面粗さ: | 1.2μm | プロセス: | ロウ付けスカイビングフィン |
| ファンライフ: | 50000時間 | 許容範囲: | 0.05 mm |
| ハイライト: | precision machined cold plate heat sink,water cooled heat sink for power amplifier,liquid cooling plate with warranty |
||
製品の説明
Precision Machined Cold Plate Water Cooled Heat Sink for Power Amplifier
Product parameters of Precision machined cold plate water cooled heat sink for power amplifier
Material: AL 6061
Size:260 * 125 * 18m
Weight: 1.85kg
Technology: CNC machined
Feature: Good cooling capability and No leakage default
Surface treatment: oil cleared,cleaned and passivation
Heat conducting power: 860W
Product advantage of Precision machined cold plate water cooled heat sink for power amplifier
If you want us to make zipper fin and pipes pressing product, we can definetely make it as we have 10 stamping machines for high efficiency zipper fin production,and pipes can also be pressing on our own, no need to worry about the speed, we are always stuggle for it, to make faster and keep quality at the same time, increase best value between customers and our company.
Precision Machined Cold Plate
Water Cooled Heat Sink for Power Amplifier
1. Basic Introduction
2. Structure & Manufacturing
- Material: Aluminum AL6061 / AL5052 / Copper
- Process:
- CNC mill internal cooling channels
- Cover plate welded / brazed / sealed
- Pressure testing, leak testing
- Channels: serpentine, spiral, multi‑pass, or optimized for amplifier layout
3. Key Features for Power Amplifiers
- High heat dissipation: suitable for 100W–several kW amplifiers
- Uniform temperature: keeps RF performance stable
- Low thermal resistance: direct machining → no interface gap
- Compact & flat: easy to mount with PA modules
- Leak‑proof design: pressure tested up to 6–10 bar
- Corrosion resistance: can use deionized water or coolant
4. Why Use It for Power Amplifiers?
- Temperature drift
- Thermal expansion
- Heat concentration
- Stabilizes gain & output power
- Extends amplifier lifetime
- Allows higher power density in smaller space
- Eliminates fan noise & dust issues
5. Typical Applications
- RF power amplifiers
- Microwave transmitters
- Broadcast power amplifiers
- Industrial high‑power amplifiers
- Military & communication amplifier modules
6. Compared to Other Coolers
- Better than air cooling: higher heat load, quieter
- Better than extruded cold plates: complex channels, higher performance
- Better than skiving heatsink: for extreme high power
